- Wall jib crane for indoor use.
- Main arm: partial rotation 180°.
- Secondary arm: partial rotation 290°.
- Cablofil provided for passage of beams.
- Pivot between the two hollow arms, for passing beams.
- For the adjustable version (PMSDR), fitted with an hydraulic cylinder and manual pump for height regulation.
- Protection: polyester powder painting 60 microns C2.
- Anthracite gray finish RAL 7016.
KITFIX
- Attachment kits for wall jib cranes PMTC PMT PMI PMA PMTL and PMICL type. These kits are to be installed on existing posts and are meant to simplify assembly. You do notneed to drill into posts. The KITFIX system allows you a simple and quick installation. Three types of attachment are possible:
- Model A: Attachment to IPE HEA or HEB-type post with plate and backplate. For this option,tell us the beam's width and depth.
- Model B: Attachment to concrete or steel post with plate and backplate. For this option, tellus the post's width and depth.
- Model C: Attachment to IPE HEA or HEB-type post with clamp. For this option, tell us the beam's width and the depth of the flange.
- In each situation, bolts are delivered with the KITFIX system.
